A Schedule 80 size chart shows the relationship between Nominal Pipe Size (NPS), outside diameter (OD), and wall thickness for Schedule 80 steel pipe. Unlike tubing dimensions, pipe size is normally identified by NPS, while the actual outside diameter remains standardized for each nominal size.
All data in the table below is derived from ASME B36.10M and applies to carbon steel and seamless steel pipes; in the event of any discrepancy, the dimensions specified in the standard document shall prevail. Please contact ALLLAND for further details.
Schedule 80 Pipe Dimensions
Schedule 80 pipe dimensions refer to the outside diameter (OD) and wall thickness (WT) specified for each Nominal Pipe Size (NPS). Unlike the outside diameter, which remains the same for a given NPS across different schedules, Schedule 80 pipes have thicker walls than Schedule 40 pipes, resulting in a smaller inside diameter (ID) and higher pressure-bearing capacity under comparable material and service conditions.
Schedule 80 dimensions are commonly specified according to ASME B36.10M for carbon steel pipes and are widely used in industrial piping systems, including oil and gas, chemical processing, power plants, and high-pressure fluid transportation.
Schedule 80 Steel Pipe Size Chart in mm
| NPS | DN | Outside Diameter (OD) | Schedule | Wall Thickness |
| 1/2″ | DN15 | 21.3 mm | SCH 80 | 3.73 mm |
| 3/4″ | DN20 | 26.7 mm | SCH 80 | 3.91 mm |
| 1″ | DN25 | 33.4 mm | SCH 80 | 4.55 mm |
| 1-1/4″ | DN32 | 42.2 mm | SCH 80 | 4.85 mm |
| 1-1/2″ | DN40 | 48.3 mm | SCH 80 | 5.08 mm |
| 2″ | DN50 | 60.3 mm | SCH 80 | 5.54 mm |
| 2-1/2″ | DN65 | 73.0 mm | SCH 80 | 7.01 mm |
| 3″ | DN80 | 88.9 mm | SCH 80 | 7.62 mm |
| 4″ | DN100 | 114.3 mm | SCH 80 | 8.56 mm |
| 5″ | DN125 | 141.3 mm | SCH 80 | 9.53 mm |
| 6″ | DN150 | 168.3 mm | SCH 80 | 10.97 mm |
| 8″ | DN200 | 219.1 mm | SCH 80 | 12.70 mm |
| 10″ | DN250 | 273.1 mm | SCH 80 | 15.09 mm |
| 12″ | DN300 | 323.9 mm | SCH 80 | 17.45 mm |
| 14″ | DN350 | 355.6 mm | SCH 80 | 19.05 mm |
| 16″ | DN400 | 406.4 mm | SCH 80 | 21.44 mm |
| 18″ | DN450 | 457.2 mm | SCH 80 | 23.83 mm |
| 20″ | DN500 | 508.0 mm | SCH 80 | 26.19 mm |
| 24″ | DN600 | 610.0 mm | SCH 80 | 30.96 mm |
Schedule 80 Pipe Inside Diameter Size Chart
| NPS | OD | SCH 80 WT | Approx. ID |
| 1/2″ | 21.3 | 3.73 | 13.84 |
| 1″ | 33.4 | 4.55 | 24.3 |
| 2″ | 60.3 | 5.54 | 49.22 |
| 3″ | 88.9 | 7.62 | 73.66 |
| 4″ | 114.3 | 8.56 | 97.18 |
| 6″ | 168.3 | 10.97 | 146.36 |
| 8″ | 219.1 | 12.7 | 193.7 |
| 10″ | 273.1 | 15.09 | 242.92 |
| 12″ | 323.9 | 17.45 | 288.99 |
The calculation formula used is: ID = OD − 2 × WT.
