Applied by electrostatic fusion and high-temperature curing, FBE Steel Pipe forms a durable epoxybarrier with exceptional adhesion, impact resistance, and cathodic protection performance. Designedfor oil, gas, water, and chemical transmission systems, it ensures over 30 years of reliable anti-corrosion service in harsh environments.
Alllandsteel is a steel pipe manufacturer based in China with 25 years of experience.
The facility spans 22,000 square meters, represents a RMB 700 million investment, and operates four production lines (JCOE, ERW, SMLS, SSAW) alongside five coating lines.
With an annual production capacity of 250,000 tons, the factory covers specifications ranging from Ø406 to Ø1524 and holds multiple international certifications (API/ASTM/EN/ISO/JIS). Focused on steel pipes, creating value for you!
HOT PRODUCTS
POPULAR ARTICLES
O.D.:
Φ60mm – 3000mm (2″ – 118″)
W.T.:
5 – 40mm (0.2″ – 1.6″)
Length:
6m – 18m (20″ – 60″)
Process:
ISO 21809-2 · CSA Z245.20 · NACE RP0394 · API · ASTM · EN · GB
Coating OptionsSingle-Layer FBE · Dual-Layer FBE · 3LPE / 3LPP — available for project-specific applications
FBE steel pipe uses a fusion-bonded epoxy coating applied by electrostatic spraying and cured at 200–250 °C. The process creates a dense, chemically bonded film that forms a continuous corrosion-resistant barrier tightly adhered to the steel surface.
The coating provides outstanding adhesion, impact resistance, and cathodic disbondment protection under demanding soil and temperature conditions. It prevents moisture or ion penetration, ensuring long-term reliability in oil, gas, water, and chemical pipelines—both buried and offshore.
Each pipe undergoes automated blasting, pre-heating, and electrostatic coating with precise temperature control to ensure uniform thickness and consistent bonding strength across all diameters.
| Product Name | FBE Steel Pipe · Fusion Bonded Epoxy Coated Pipe · Epoxy Coated Steel Pipe |
| Outer Diameter | 60 mm – 3000 mm |
| Wall Thickness | 5 mm – 40 mm |
| Length | 6 m / 12 m / 18 m (customizable) |
| Ends | Plain ends · Bevelled ends (30° ± 5°) · Flanged |
| Surface Treatment | Single-Layer FBE / Dual-Layer FBE — as per project requirement |
| Standard | Steel Grade |
| API SPEC 5L | Gr.B, X42 โ€“ X80 (PSL1 / PSL2) |
| ASTM A53 / A106 / A252 | Gr.A, Gr.B, Gr.C |
| EN 10217 / EN 10219 | S235, S275, S355 ยท L245 โ€“ L485 |
| GB/T 9711 | L245 โ€“ L485 |
The FBE coating process includes surface blasting, pre-heating, electrostatic powder application, and high-temperature curing. The fusion-bonded epoxy melts and cross-links to form a uniform, strongly adhered layer that provides durable corrosion and impact protection for buried and subsea pipelines.
FBE steel pipes are widely used in oil, gas, water, and industrial pipeline systems requiring long-term corrosion protection. Their fusion-bonded epoxy coating provides excellent adhesion and chemical resistance, ensuring durable performance in buried, marine, and above-ground installations.
Oil & Gas Pipelines
Applied in crude oil, natural gas, and fuel transmission lines where corrosion resistance and coating integrity are essential for safe, long-distance operation.
Water Transmission & Utilities
Used for potable water, cooling, and desalination systems to prevent rust contamination and maintain pipeline cleanliness.
Chemical & Industrial Systems
Ideal for chemical plants, refineries, and industrial fluid transport exposed to aggressive or corrosive media.
Offshore & Subsea Pipelines
Provides long-lasting protection against seawater, pressure fluctuations, and mechanical impact in marine environments.
Infrastructure & Energy Projects
Used in buried or exposed pipeline networks within power generation, municipal, and construction projects requiring durable anti-corrosion coatings.
FBE steel pipes are carefully packaged to prevent coating damage during loading and transit. Each pipe is fitted with protective end caps, separated by soft spacers, and securely wrapped to maintain surface integrity and stability throughout shipping.
Our factory’s coating production line is available for viewing.
