Welcome to ALLLAND Steel Pipe Manufacturing.GOST 10704 45 Steel Pipe is an electrically welded longitudinal steel pipe manufactured from Steel 45 carbon steel and supplied according to applicable GOST 10704 dimensional requirements. Available in a range of outside diameters and wall thicknesses, it is suitable for mechanical components, equipment fabrication, industrial machinery, and general engineering applications. Pipe dimensions, surface treatment, end preparation, and inspection documents can be supplied according to project requirements.
Alllandsteel is a steel pipe manufacturer based in China with 25 years of experience.
The facility spans 22,000 square meters, represents a RMB 700 million investment, and operates four production lines (JCOE, ERW, SMLS, SSAW) alongside five coating lines.
With an annual production capacity of 250,000 tons, the factory covers specifications ranging from Ø406 to Ø1524 and holds multiple international certifications (API/ASTM/EN/ISO/JIS). Focused on steel pipes, creating value for you!
HOT PRODUCTS
POPULAR ARTICLES
GOST 10704 45 Steel Pipe is a longitudinally welded steel pipe made from Steel 45, offering good strength, durability, and dimensional consistency. GOST 10704 is a Russian standard specifying the assortment and dimensions of electrically welded steel pipes.
Available in various outside diameters and wall thicknesses, it is commonly used for mechanical structures, equipment components, engineering fabrication, and general industrial applications.
O.D.:
10–1420 mm — Available according to GOST 10704 size specifications
W.T.:
1.0–40 mm — Selected according to pipe diameter and project requirements
Length:
5.8–12 m — Fixed or random lengths available according to order requirements
Pipe Type:
Electrically Welded / Longitudinal Welded
Standards:
GOST 10704-91, GOST 1050
Steel Grades:
Grade 45
Tube Ends& Surface Treatment:
Plain End / Beveled End
Black / Bare / 3LPE / 3LPP / FBE / HDG
Packaging:
Steel Straps / Protective Caps / Waterproof Wrapping / Bundled or Loose Packing
The above dimensions represent typical available sizes. Actual OD, wall thickness, and length can be customized according to GOST 10704, production capabilities, and project requirements.
| Standard / Grade | What It Defines |
| GOST 10704-91 | Electrically welded longitudinal pipe assortment and dimensions |
| Steel 45 | Carbon steel material grade |
| GOST 1050 | Requirements for Steel 45 material |
| GOST 10705 / 10706 | Related technical requirements for welded steel pipes |
The typical chemical composition of Steel 45 carbon steel is shown below:
| Element | Content |
| Carbon (C) | 0.42–0.50% |
| Silicon (Si) | 0.17–0.37% |
| Manganese (Mn) | 0.50–0.80% |
| Sulfur (S) | ≤0.040% |
| Phosphorus (P) | ≤0.035% |
| Chromium (Cr) | ≤0.25% |
| Nickel (Ni) | ≤0.30% |
| Copper (Cu) | ≤0.25% |
Note: Chemical composition should be confirmed according to the applicable GOST 1050 edition and the specific material certificate (MTC).
The typical mechanical properties of Steel 45 are shown below:
| Property | Typical Value |
| Tensile Strength | ≥600 MPa |
| Yield Strength | ≥355 MPa |
| Elongation | ≥16% |
| Hardness | ≤197 HB |
| Impact Toughness | According to applicable specification |
Note: Mechanical properties may vary depending on pipe size, delivery condition, heat treatment, and applicable GOST 1050 requirements. Final values should be confirmed by the MTC and project specification.
GOST 10704 Grade 45 Steel Pipe is available in a wide range of outside diameters and wall thicknesses to meet different engineering and fabrication requirements.
| Outside Diameter (mm) | Wall Thickness (mm) | Typical Length (m) |
| 10 | 1.0–1.5 | 5.8–12 |
| 20 | 1.5–2.5 | 5.8–12 |
| 25 | 1.5–2.5 | 5.8–12 |
| 32 | 1.5–3.0 | 5.8–12 |
| 38 | 1.5–3.5 | 5.8–12 |
| 45 | 1.5–4.0 | 5.8–12 |
| 48 | 1.5–4.0 | 5.8–12 |
| 57 | 1.5–4.5 | 5.8–12 |
| 76 | 2.0–5.0 | 5.8–12 |
| 89 | 2.0–6.0 | 5.8–12 |
| 108 | 2.0–6.0 | 5.8–12 |
| 133 | 2.5–7.0 | 5.8–12 |
| 159 | 3.0–8.0 | 5.8–12 |
| 219 | 4.0–10.0 | 5.8–12 |
| 273 | 5.0–12.0 | 5.8–12 |
| 325 | 5.0–14.0 | 5.8–12 |
| 426 | 6.0–16.0 | 5.8–12 |
| 530 | 6.0–20.0 | 5.8–12 |
| 630 | 7.0–22.0 | 5.8–12 |
| 720 | 8.0–25.0 | 5.8–12 |
| 820 | 8.0–28.0 | 5.8–12 |
| 920 | 10.0–30.0 | 5.8–12 |
| 1020 | 10.0–32.0 | 5.8–12 |
| 1220 | 10.0–36.0 | 5.8–12 |
| 1420 | 12.0–40.0 | 5.8–12 |
Note: The sizes above are typical available configurations for reference. Actual outside diameter, wall thickness, length, and tolerances should be confirmed against the applicable GOST 10704 requirements and specific project specifications.
For projects in Russia, Kazakhstan, and other GOST-standard markets, this product is commonly specified based on the following requirements:
Steel 45 is a medium-carbon steel grade offering a balance of strength, hardness, and machinability. Compared with lower-carbon grades such as Steel 20 and Steel 35, Steel 45 generally provides higher strength and hardness potential, while 09G2S is a low-alloy grade commonly used where low-temperature performance is required.
| Steel Grade | Carbon Content | Key Characteristics | Typical Applications |
| Steel 20 | 0.17–0.24% | Good weldability and ductility | General fabrication, structural components |
| Steel 35 | 0.32–0.40% | Moderate strength and machinability | Mechanical components, engineering applications |
| Steel 45 | 0.42–0.50% | Good strength, hardness, and machinability | Mechanical structures, equipment components |
| 09G2S | ≤0.12% | Low-alloy composition, good low-temperature performance | Structural and engineering applications |
For GOST 10704 Grade 45 Steel Pipe, the appropriate grade should be selected according to the required mechanical properties, weldability, operating conditions, and project specifications.
GOST 10704 Grade 45 Steel Pipe is primarily used in Russia, Kazakhstan, and other GOST-standard markets for mechanical and fabrication applications requiring good strength and machinability.
GOST 10704 Grade 45 Steel Pipe is primarily used in Russia, Kazakhstan, and other GOST-standard markets for mechanical and fabrication applications requiring good strength and machinability.
Applied in the fabrication of machinery, equipment structures, brackets, supports, and welded assemblies for mechanical and engineering applications.
Suitable for machine bases, support structures, conveyor components, and other welded parts used in industrial machinery.
Used for custom-fabricated frames, supports, and load-bearing components where GOST 10704 dimensions and Steel 45 material requirements are specified.
GOST 10704-91 is a Russian standard for electrically welded steel pipes, covering their assortment and dimensional requirements.
Steel 45 is a Russian carbon steel grade that is broadly comparable to AISI 1045 in carbon content and general material characteristics. Exact equivalence should be confirmed against the applicable material standards and chemical and mechanical requirements.
No. In GOST 10704 45, “45” refers to Steel 45, the material grade, not a 45 mm pipe diameter. A 45 mm outside diameter is a separate dimensional specification.
